CONVERSION SPECIFICATION: IN-FLOOR FOLD OUT

• DOOR OPENING HEIGHT 54" 54 1/4"
• DOOR OPENING WIDTH 31 3/8" 31 3/8"
• INTERIOR HEIGHT AT CENTER OF VAN 58 1/4" 59 1/4"
• INTERIOR HEIGHT AT DRIVER’S POSITION 56 3/4" 57 3/4"
• FLOOR WIDTH AT DRIVER’S POSITION 64" 64"
• FLOOR LENGTH BEHIND FRONT SEATS 56 1/8" 56 1/8"
• OVERALL FLOOR LENGTH 84" 84"
• RAMP LENGTH 52 1/2" 53"
• RAMP WIDTH 30" 29 3/4"
• RAMP ANGLE WHEN KNEELED 10 DEGREES 8 1/2 DEGREES
• RAMP CAPACITY 750 LBS 750 LBS
• GROUND CLEARANCE 5 3/4" 6 1/4"

CONVERSION SPECIFICATION: IN-FLOOR FOLD OUT

• DOOR OPENING HEIGHT 54" 54 1/4"
• DOOR OPENING WIDTH 31 3/8" 31 3/8"
• INTERIOR HEIGHT AT CENTER OF VAN 58 1/4" 59 1/4"
• INTERIOR HEIGHT AT DRIVER’S POSITION 56 3/4" 57 3/4"
• FLOOR WIDTH AT DRIVER’S POSITION 64" 64"
• FLOOR LENGTH BEHIND FRONT SEATS 56 1/8" 56 1/8"
• OVERALL FLOOR LENGTH 84" 84"
• RAMP LENGTH 52 1/2" 53"
• RAMP WIDTH 30" 29 3/4"
• RAMP ANGLE WHEN KNEELED 10 DEGREES 8 1/2 DEGREES
• RAMP CAPACITY 750 LBS 750 LBS
• GROUND CLEARANCE 5 3/4" 6 1/4"

AVAILABLE COLORS

• BLACK
• ARCTIC FROST PEARL
• NATURAL WHITE
• SILVER SHADOW PEARL
• SLATE METALLIC
• SALSA RED PEARL
• DESERT SAND MICA
• SILVER PINE MICA
• BLUE MIRAGE METALLIC

VEHICLE SPECIFICATIONS



• VEHICLE LENGTH 200"
• VEHICLE WIDTH 77 3/8"
• VEHICLE HEIGHT 68 7/8"
• VEHICLE WHEELBASE 119 5/16"
• ENGINE SIZE 3.5 LITER V6
• ENGINE HORSE POWER 266
• EST.FUEL ECONOMY 19 CITY/ 27 HWY MPG
